3. Quick Tour

3.1 Starting the TM and Registering the Editor Used

When the TM has been installed normally, the TM can be started by selecting [Start] -> [Programs] -> [RENESAS-

TOOL] -> [TM V.3.xx] -> [TM] from the Start menu. When the TM starts up, the Project Bar appears.

Fig. 3-1 Project Bar in Floating State

When started for the first time, the Project Bar is in a “floating” state. Grasp this window and bring it to the top of the

screen, and you can have it located at the uppermost part of the desktop.

Fig. 3-2 Project Bar Pasted at The Top

Next, register the editor you normally use.
Press the

button. A dialog box for registering an editor appears.

Fig. 3-3 Dialog Box for Registering an Editor
