4.4 Inspector

4.4.1 Overview

Inspector is the window which indicates function information and variable information. Information on the made

object is analyzed statically in the cause. Each information is classified with the tab, and indicated respectively in the
list.

A file name and a line number are outputted by each information, and it is possible that it opens with text editor.

4.4.2 Inspector Window

Menu bar

Toolbar

List window

Preview window

Fig. 4-50 Inspector Window

4.4.3 Starting the Inspector

Use the Project Bar to start the Inspector and display various information.

Specify function or variable name

Show function definition

Show function reference

Show variable definition

Show variable reference

Detail settings of Inspector

Fig. 4-51 Inspector Startup Buttons
