53
4.1.4.5 Application Tool Information Dialog Box
The Application Tool Information dialog box is provided for registering an application.
Fig. 4-11 Application Tool Information Dialog Box
■ Name (essential)
Enter an application name.
■ File Path (essential)
Enter a path to the application’s execution file. The file can also be selected by clicking the Browse button.
■ Current button
The current directory from which to start the application can be specified. By default, this is the directory where the
application’s execution file is stored. Clicking the Current button opens the Current Directory dialog box.
■ Etc(Version)
Use this text box to set version or other desired information.
■ Parameter
Enter the options or parameters the application uses. Write the following parameters, and the project file name, target
chip name, etc. can be passed to the application.
z %P Project file name
z %W Working directory
z %X Target program name
z %T Target chip name
■ Set parameter before executing
Turn this check box on, and a dialog box opens when the application starts up, allowing you to specify startup options
and parameters.
■ Environment
This field shows environment variables used by the application.
■ Add button
Click this button when you want to add an environment variable. The Environment Settings dialog box opens.
■ Delete button
To delete any environment variable, select it from the list and click the Delete button.
