8-20 hsb 2 PLUS Series LCD Display
EMC Co
nf
or
m
an
ce
EMC Conformance
Always check the installation before going to sea to make sure that it is not
affected by radio transmissions, engine starting etc.
8.8 Integrated Systems
The hsb 2 series displays can be linked to other equipment to transfer data as
follows:
• Additional displays, either CRT or LCD, can be connected via hsb 2 (and
SeaTalk) to repeat fishfinder, chart and/or radar information at a remote
location.
• Data can be received via SeaTalk or NMEA, some of which will increase
the functionality of the display. Other data can be viewed on the display.
• Data can be transmitted via SeaTalk and NMEA to enhance other equip-
ment.
• Some incoming data can be converted across the communication link and
re-transmitted - see Data Conversion on page 8-30.
Power for External Equipment
External equipment cannot be powered from the display’s SeaTalk
interface. It must be powered from the ship’s supply or via a SeaTalk bus.
Ensure correct polarity of the SeaTalk connection.
For systems where the ship’s power source is 24 V only, you may need to
install a 24 V to 12 V DC converter. This is only necessary if the products
being connected to the display are:
• SeaTalk compatible (for example, compass, GPS and instruments), and
there is no existing SeaTalk bus
• NMEA compatible, but operate only from 12 V (for example, compass,
GPS and some navigators)
The DC~DC converter must conform to the following specification:
hsb
2 ™ (High Speed Bus) Multiple Display Systems
You can connect several hsb 2 displays; the number is dependent on cable
length - see hsb 2 Cable on page 8-8. The system can include existing HSB
Table 8-2: DC-DC Converter for External Equipment
Input 21 to 32 V DC
Output 13.6 V DC, isolated
Load Continuous current rating, in excess of required load
