7-18 hsb 2 PLUS Series LCD Display
C
ha
rt Set
Up
Pa
ra
m
eters
7.7 Chart Set Up Parameters
The CHART SET UP option allows you to set up the chartplotter according to
your system configuration and your personal preferences.
The following table lists the Chart Set up parameters and their options, shows
the factory default setting, and provides a space for you to make a note of your
new default setting. Each parameter is described in the following subsections.
Customize Chart
This provides a list of chart options, enabling you to specify how the chart
features are displayed. Most options can be toggled between on, off and
custom - custom passes on/off control to the SCREEN soft keys (see
Customizing the Screen Presentation Options on page 2-13).
The following features can be set using Customize Chart, factory default
settings are shown in bold type:
• chart text (on, off, custom)
Table 7-7: Chart Set Up Parameters
Parameter Options Factory Default New Default
CUSTOMIZE CHART See below for details
PLOTTER MODE OFF, ON OFF
CHART
ORIENTATION NORTH UP, COURSE UP,
HEAD UP NORTH UP
OBJECT
INFORMATION OFF, ON POINTS, ON ALL ON ALL
WAYPOINT SYMBOLS OFF, ON ON
WAYPOINT NUMBERS OFF, OFF ON
DEFAULT WAYPOINT
SYMBOL
, , ,
HEADING VECTOR OFF, 3 MINS, 10 MINS,
INFINITE OFF
COG VECTOR OFF, 3 MINS, 10 MINS,
INFINITE OFF
TIDE VECTOR OFF, 10 MINS, 1 HOUR,
INFINITE OFF
RADAR/CHART
SYNCH OFF, ON OFF
DATUM SELECTION WGS 84, LOCAL WGS 84
POSITION OFFSET SET UP, OFF/ON OFF
