7-12 hsb 2 PLUS Series LCD Display
R
ada
r Set
U
p
Pa
ra
m
eters
7.4 Radar Set Up Parameters
The RADAR SET UP option allows you to set up the radar according to your
system configuration and your personal preferences.
Note: Some parameters can only be changed if you are using the Master dis-
play (that is, the display to which the scanner is connected).
The following table lists the Radar Set Up parameters and their options,
shows the factory default setting, and provides a space for you to make a
note of your new default setting. Each parameter is described in the fol-
lowing subsections.
EBL Display
The mode of the bearing data displayed for Electronic Bearing Lines
(EBLs). The bearing information can be displayed in either of two forms:
• Relative: The bearing relative to your vessel’s heading.
• Mag/True: The actual bearing in either degrees magnetic or degrees true.
This option is only available if you are obtaining data from a compass.
If you choose this mode, the selection you made for Bearing Mode
determines whether °M or °T is displayed in the EBL data boxes. The
current units are shown for the heading value in the status bar at the top
of the screen.
Table 7-2: Radar Set Up Parameters
Parameter Options Factory Default New Default
EBL DISPLAY MAG/TRUE, RELATIVE RELATIVE
TIMED
TRANSMIT OFF, ON OFF
TRANSMIT PERIOD 10 scans, 20 scans, 30 scans 20 scans
STANDBY PERIOD 3, 5, 10 or 15 mins 10 minutes
DEFAULT MARK
SYMBOL
, , ,
MARK DISPLAY OFF, ON ON
CLEAR MARKS Press soft key to clear marks
database N/A
CUSTOM SCALE OFF, ON,SET RANGES... OFF
BEARING
ALIGNMENT Slider value 0°
ANTENNA SIZE 4 ft., 6ft (only if an open array
scanner is connected) 4 ft.
SEND ON HSB ON, OFF ON
