Chapter 6. Troubleshooting
6.1 Flowchart to Remedy the Troubles
Figure 6.1 shows the flowchart to remedy the troubles from when power to the emulator is activated
until emulator debugger M3T-PD38 starts up (Program Window displayed).
Troubleshooting until the emulator
system starts up
M3T-PD38 Init dialog box displayed
Starting up the M3T-PD38 (part 2)
Close the Init dialog box
(click the OK button).
M3T-PD38 Program Window displayed
Emulator system has started up
normally
Display normal
Display normal
Display normal
Refer to "6.1 (2) When the LED Display of the
PC4701 is Abnormal" (page 43).
Display not normal/Error occurred
Refer to "6.1 (3) When the Init Dialog is Not
Displayed Normally" (page 43).
Display not normal/Error occurred
Refer to "6.1 (4) When the Program Window is
Not Displayed Normally" (page 44).
Display not normal/Error occurred
Figure 6.1 Troubleshooting when starting up the emulator system
Starting up the M3T-PD38 (part 1)
Start up the M3T-PD38 by double-click
on the M3T-PD38 icon.
Display of the PC4701 front panel LED
Starting up the emulator
(Turn ON the emulator and the target
system simultaneously.)
Refer to "4.1 Turning On the Power Supply"
(page 32) and PC4701 User's Manual.
Can not power on
Power on
