Chapter 5. Specifications
5.1 Specifications
Table 5.1 lists the specifications of the M38000TL2-FPD.
Table 5.1 Specifications of the M38000TL2-FPD
*1 Subject to limits depending on MCU's specifications. However, the maximum operating range
is 16.8 MHz only for the M38049RLSS MCU.
*2 Subject to limits depending on MCU's specifications.
*3 RLSS/RLFS represent the emulator MCUs that can operate with supply voltages below 2.0 V.
PC4701
740 Family MCUs which have an emulator MCU
Single-chip mode
Memory expansion mode
Microprocessor mode
64 KB
16 MHz (Vcc = 5.0 V)* 1
RSS/RFS type 2.0 - 5.5 V* 2
RLSS/RLFS type* 3 0.9 - 5.5 V* 2
Max. 3 bytes
38000 Series 2 addresses $FFFE, $FFFF
Other than 38000 Series 2 addresses $8000, $8001
5 to 35 ° C (no dew)
-10 to 60 ° C (no dew)
Supplied from PC4701
Connected via the emulator MCU which varies depending on
the MCU, probe direction converter board and the flexible
cable for connecting the target system. For the connection,
refer to " 3.4 Connecting the Emulator MCU" (page 23).
U.S. EMI standards (FCC part 15 Class A)
CE marking (EN55081-1, EN55082-1)
Emulator
Applicable MCUs
Usable modes
Emulation memory
Maximum operating frequency
Applicable power voltage
Stack capacity of emulator
MCU addresses of emulator
Operating temperature
Storage temperature
Power supply to emulation pod
Connection to target system
International standards
