Renesas M38000TL2-FPD - Manual (Page 18)

( 16 / 54 )
Please keep the M38000TL2-FPD's packing box and cushion material in your place for reuse at a later
time when sending your product for repair or other purposes. Always use these packing box and
cushion material when transporting the M38000TL2-FPD.
If any of these items are missing or found faulty, please contact your local distributor. Also, if there
is any question or doubt about the packaged product, contact your local distributor.
2.2 Other Tool Products Required for Development
To bring forward programs development on the 740 Family MCUs, the products listed below are
necessary in addition to the package components listed above. Get them separately.
Other tool products
To purchase these products, contact your local distributer.
Chapter 2. Preparation
2.1 Package Components
This product consists of the following items. When unpacking, check to see if your product package
contains all of these items.
Package components
Item
M38000TL2-FPD emulation pod main unit
PCA7733 REV.B flexible cable for connecting the PC4701
28DP-WS 28-pin DIP-type probe direction converter board
32LCC-S 32-pin LCC-type probe direction converter board
M38000TL2-PSW RESET, GND and Vcc cables with overcurrent protective circuits
Screws for securing the PC4701
Hardware tool user registration FAX sheet (English)
Hardware tool user registration FAX sheet (Japanese)
M38000TL2-FPD User's Manual (this manual)
M38000TL2-FPD User's Manual (Japanese)
Quantity
1
1
1
1
1
2
1
1
1
1
Emulator main unit
Emulator debugger
Emulator MCUs
Temporary target board
Converter board
PC4701
M3T-PD38
M3xxxxRSS/RFS (RLSS/RLFS)
M3xxxxT-ADS/ADF
(required when the target system is not connected)
A converter board for your MCU is required. For details on the
converter board, refer to "3.4 Connecting the Emulator MCU" (page
23) or the Accessory Guide.
