Chapter 13: KSX II Local Console
252
Hot key: Take this action:
Double Click Caps Lock Press Caps Lock key twice quickly
Double Click Left Alt key Press the left Alt key twice quickly
Double Click Left Shift key Press the left Shift key twice quickly
Double Click Left Ctrl key Press the left Ctrl key twice quickly
4. Set the Video Switching Delay from between 0 - 5 seconds, if
necessary. Generally 0 is used unless more time is needed (certain
monitors require more time to switch the video).
5. If you would like to use the power save feature:
a. Select the Power Save Mode checkbox.
b. Set the amount of time (in minutes) in which Power Save Mode
will be initiated.
6. Choose the resolution for the KSX II Local Console from the
drop-down list:
 800x600
 1024x768
 1280x1024
7. Choose the refresh rate from the drop-down list:
 60 Hz
 75 Hz
8. Choose the type of local user authentication:
 Local/LDAP/RADIUS. This is the recommended option. For more
information about authentication, see Remote Authentication
(on page 36).
 None. There is no authentication for Local Console access. This
option is recommended for secure environments only.
9. Select the "Ignore CC managed mode on local port" checkbox if you
would like local user access to the KSX II even when the device is
under CC-SG management.
Note: If you initially choose not to ignore CC Manage mode on the
local port but later want local port access, you will have to remove
the device from under CC-SG management (from within CC-SG).
You will then be able to check this checkbox.
