32176 Group
Starter Kit User’s Manual M3A-2152
REJ10B0224-0310/Rev.3.10 Mar. 2008 Page 11 of 83
4. Starter Kit Usage Conditions
The following shows the conditions under which the Starter Kit can be used.
4.1 Ambient Conditions
Table 4.1 shows the ambient conditions under which the Starter Kit can be used.
Table 4.1 Operating Environment
Symbol Parameter Rated value Remarks
Operating ambient temperature when
connecting to emulator
5
o
C to 35
o
C
Topr
Operating ambient temperature when
using evaluation board by itself
0
o
C to 70
o
C
Storage ambient temperature for
emulator
-10
o
C to 60
o
C
Tstr
Storage ambient temperature for
evaluation board
0
o
C to 70
o
C
No dewdrops allowed.
Corrosive gas environment not
allowed.
4.2 Host PC Condition
It is recommended that each software included with the Starter Kit be run on the host PC under
the OS listed in Table 4.2.
Table 4.2 Host PC Conditions
Starter Kit Type Name M3A-2152G52A M3A-2152G52
Host PC IBM PC/AT compatibles
CPU Pentium III 500MHz or higher CPU is recommended
Memory 192 Mbytes or more system memory is recommended
OS Windows 2000, XP Windows 98, Me, NT4.0, 2000
USB Port 1 port (required) —
LPT Port — 1 port (required)
4.3 Conditions for the Power Supply Used
Table 4.3 shows power supply specifications required when using the Starter Kit.
Table 4.3 Power Supply Specifications
Symbol Power supply voltage Power supply current
VCC 4.75 V to 5.25 V 1A
GND 0V (reference voltage) —
