Chapter 1: Introduction
8
Item Description
AC power cord plug
See Power Control (on page 158) for additional
information.
Power on/off switch
LAN 3 port
Note: The LAN 3 port is reserved for future use.
LAN1 and LAN2 ports
See Step 3: Connect the Equipment for additional
information.
Admin port
See Step 3: Connect the Equipment for additional
information.
External modem port
See Modem Configuration (on page 257) for additional
information.
Reset button
See Resetting the KSX II Using the Reset Button (on
page 256) for additional information.
Local port
See Step 3: Connect the Equipment for additional
information.
KVM ports
See Step 3: Connect the Equipment for additional
information.
Power Ctrl. 1 and Power Ctrl. 2
See Power Control (on page 158) for additional
information.
Serial ports
See Step 3: Connect the Equipment for additional
information.
