Preface
The M30220TF-PRB is a pod probe for flash memory rewrite mode debug of the M30220 and
M30221 Group of Renesas 16-bit MCUs. The M30220TF-PRB is used by connecting to a PC4701
emulator main unit and the M30200T-RPD-E emulation pod main unit. This product can debug the
CPU rewrite mode.
CPU rewrite mode debug is a function for debugging rewrites of internal flash memory using your
application software. For details on specifications and writing conditions of CPU rewrite mode, refer
to the user's manual of M30220 Group MCUs.
This manual mainly explains specifications, how to set up the M30220TF-PRB and the debugging
procedure for CPU rewrite mode. For detail information about the emulator main unit, emulation pod
main unit, and emulator debugger, refer to each user's manual.
Emulator main unit: PC4701 User's Manual
Emulation pod main unit: M30200T-RPD-E User's Manual
Emulator debugger: M3T-PD30 User's Manual
To check the components of this product, refer to "2.1 Package Components" (page 14) in this
manual. If there is any question or doubt about this product, contact your local distributor.
To use the product properly
Precautions for Safety:
• Both in this User's Manual and on the product itself, several icons are used to insure
proper handling of this product and also to prevent injuries to you or other persons,
or damage to your properties.
• The icons' graphic images and meanings are given in "Chapter 1. Precautions for
Safety". Be sure to read this chapter before using the product.
