Chapter 2. Preparation
2.1 Package Components
This product consists of the following items. When unpacking, check to see if your product package
contains all of these items.
Table 2.1 Package components
Please keep the M30220TF-PRB's packing box and cushion material in your place for reuse at a later
time when sending your product for repair or other purposes. Always use these packing box and
cushion material when transporting the M30220TF-PRB.
If any of these items are missing or found faulty, please contact your local distributor. Also, if there
is any question or doubt about the packaged product, contact your local distributor.
2.2 Other Tool Products Required for Development
To bring forward programs development on the M30220 and M30221 Group MCUs, the products
listed below are necessary in addition to the package components listed above. Get them separately.
Table 2.2 Other tool products
To purchase these products, contact your nearest distributer.
Emulator main unit
Emulation pod main unit
Emulator debugger
Converter board
PC4701
M30200T-RPD-E
M3T-PD30 Ver.4.00 or later
For 144-pin LQFP (144P6Q-A): FLX-144NSD
For 144-pin TQFP (144PFB-A): FLX-144NSE
For 120-pin LQFP (120P6R-A): FLX-120NSE
The converter board which matches to the foot pattern of the target
system is required.
Item
M30220TF-PRB pod probe for flash memory rewrite mode debug of M30220 and M30221
Group MCUs
Screws for fixing pod probe
Floppy disk (custom program file)
M30220TF-PRB User's Manual (this manual)
M30220TF-PRB User's Manual (Japanese)
M30220TF-PRB Repair Request Sheet (English/Japanese)
