Chapter 5. Specifications
5.1 Specifications
Table 5.1 lists the specifications of the M30220TF-PRB.
Table 5.1 Specifications of the M30220TF-PRB
PC4701
M30200T-RPD-E
M30220 and M30221 Group MCUs
Single-chip mode
1 MB
(128 K - 32) bytes (Address E0000h - FFFDFh; For how to
use the flash memory, refer to Chapter 4.)
Guaranteed for only 100 program/erase iterations
2.7 - 5.5 V
10.0 MHz
7.0 MHz, 1-wait
For no-wait: 5.0 MHz or less
For 1-wait: 10.0 MHz or less
Max. 8 bytes
16-byte dump: approx. 312 BCLK cycles
16-byte fill: approx. 283 BCLK cycles
1. Supplied from the emulator main unit
2. The operating voltage of the emulation pod main unit is
determined by detecting the supply voltage of the target
system. When no target system is connected, or when the
supply voltage of the target system is more than 5.0 V, the
operating voltage is 5.0 V.
5 to 35
°
C (no dew)
20 to 30
°
C (in CPU rewrite mode)
-10 to 60
°
C (no dew)
M30220 Group:
FLX-144NSD (separately available)
for 144-pin 0.5-mm-pitch LQFP (144P6Q-A)
FLX-144NSE (separately available)
for 144-pin 0.4-mm-pitch TQFP (144PFB-A)
M30221 Group:
FLX-120NSE (separately available)
for 120-pin 0.4-mm-pitch LQFP (120P6R-A)
Emulators
Emulation pod main unit
Applicable MCUs
Usable MCU mode
Emulation memory
Flash memory
Program/erase iterations of flash memory
Operating power voltage
Operating frequency 4.0 - 5.5 V
2.7 - 5.5 V
Operating frequency
in CPU rewrite mode
Stack capacity for the emulator
Suspended cycles in run-time debug
Power supply to emulation pod
Operating temperature range
Storage temperature range
Connection to the target system
See "3.4 Connecting the Target
System" (page 22).
