Appendix A Specifications
© National Instruments Corporation A-5 NI PCI-6110/6111 User Manual
Analog Output
Output Characteristics
Number of channels ............................... 2 voltage
Resolution .............................................. 16 bits, 1 in 65,536
Max update rate
1 channel ......................................... 4 MS/s, system dependent
2 channel ......................................... 2.5 MS/s, system dependent
FIFO buffer size ..................................... 2,048 samples
Data transfers ......................................... DMA, interrupts,
programmed I/O
DMA modes ........................................... Scatter gather (single transfer,
demand transfer)
Transfer Characteristics
Relative accuracy (INL)......................... ±4 LSB typ, ±8 LSB max
DNL ....................................................... ±2 LSB typ, ±8 LSB max
Voltage Output
Ranges .................................................... ±10 V
Output coupling...................................... DC
Output impedance .................................. 50
Ω, ±5%
Short circuit current ............................... ±27 mA typ
Table A-3. NI PCI-6110/6111 Analog Output DC Accuracy Information
Nominal
Range (V)
Absolute Accuracy
% of Reading
Offset
(mV)
Temp Drift
(%/°C)
Absolute Accuracy
at Full Scale (±mV) 24 Hrs 1 Year
±10 0.018 0.022 5.933 0.0005 8.133
Note: Temp Drift applies only if ambient is greater than ±10 °C of previous external calibration.
