© National Instruments Corporation A-1 Xmath Interactive Control Design Module
A
Using an Xmath GUI Tool
This appendix describes the basics of using an Xmath GUI tool.
Overview
ICDM was developed using the programmable Xmath GUI (Graphical
User Interface). Using a graphical tool such as ICDM is quite different from
using a toolbox that has a traditional command-line user interface.
To see a menu of Programmable GUI examples, enter guidemo from the
Xmath command area. This displays the menu of GUI demos shown in
Figure A-1.
1. Select a demo (for example, Variable Binding).
2. Click OK.
In a few seconds the demo will appear. Your window manager may require
you to position the window(s) generated by the demo—this is done by
dragging the window to the desired location.
Note You can run several demos simultaneously.
