ni© National Instruments Corporation
E-1
E
Front Panel and Connectors
This appendix describes the front panel and connectors on the PXI-8170
Series embedded computer.
The PXI-8170 Series has the following front panel connectors:
•
VGA Controller
•
Extended Capabilities Parallel (ECP)
•
PS/2-Style Keyboard
•
PS/2-Style Mouse
•
Universal Serial Bus (USB)
•
RS-232 Serial
Note
The illustrations in this appendix show the mating face of the connectors.
An asterisk suffix (*) on a signal name indicates that the signal is active low.
Front Panel
Figure E-1 shows the front panel layout of the PXI-8170. The drawing
shows dimensions relevant to key elements on the front panel. Dimensions
are shown in inches and millimeters, with millimeter dimensions in square
brackets. The front panel thickness for all models in the PXI-8170 Series is
2.49 mm (0.098 in.)
