© National Instruments Corporation B-1 PXI-8170 Series User Manual
B
Specifications
This appendix lists the electrical, mechanical, and environmental
specifications of the PXI-8170 Series embedded computer, and describes
how to add RAM.
Electrical
PXI-8170 450 MHz PIII Processor
PXI-8170 700 MHz PIII Processor
Physical
Board dimensions................................... PXI 3U-size module
8.1 by 13 by 21.6 cm
(3.2 by 5.1 by 8.5 in.)
Slot requirements ................................... One system slot plus three
controller expansion slots
Voltage (V)
Current (A)
Typical Maximum
+3.3 3 A 10 A
+5 3.5 A 7 A
+12 0.05 A 1.0 A
–12 0.01 A 0.1 A
Voltage (V)
Current (A)
Typical Maximum
+3.3 2.5 A 10 A
+5 3 A 6 A
+12 0.05 A 1.0 A
–12 0.01 A 0.1 A
