Mounting the sDIO
Adept SmartController User’s Guide, Rev. E
95
Panel Mounting the sDIO
To panel mount the sDIO, install one bracket on each side of the back of the unit. Use the
screws from the accessories kit; see
Figure A-3. Panel Mounting the sDIO
10.0
18.0
346.4
4X M3 x 6MM
14.0
6.6
16.0
359.6
27.6
273.9
2X 40356-00000
R 3.6
186.5
