Chapter 4 - AdeptVision sAVI Option
76 Adept SmartController User’s Guide, Rev. E
Table 4-2. Standard Breakout Cable Strobe and Power Connector Pin Assignments
Pin Function Notes
1 User +12 VDC to cameras
2 User power return (Gnd)
3 Strobe 1
4 Strobe return (Gnd)
5 Strobe 2
6 Reserved
7 Reserved
8 Reserved
9 Shield (chassis ground)
9-Pin D-Sub Female Receptacle
