Table 4-4. Two-Camera Breakout Cable Pin Assignments
From:
Pin
To:
Pin
Function
AVI
8
CAM1
1
Power return
AVI
7
CAM1
2
+12V power
AVI
12
CAM1
3
Shield (video)
AVI
42
CAM1
4
Video
AVI
38
CAM1
5
Shield (Hd)
AVI
36
CAM1
6
Hd (horizontal drive)
AVI
37
CAM1
7
Vd (vertical drive)
AVI
38
CAM1
8
Shield (Clock)
AVI
22
CAM1
9
Clock
--
--
CAM1
10
not connected
--
--
CAM1
11
not connected
AVI
38
CAM1
12
Shield (Vd)
AVI
6
CAM2
1
Power return
AVI
5
CAM2
2
+12V power
AVI
43
CAM2
3
Shield (video)
AVI
29
CAM2
4
Video
AVI
35
CAM2
5
Shield (Hd)
AVI
34
CAM2
6
Hd (horizontal drive)
AVI
19
CAM2
7
Vd (vertical drive)
AVI
35
CAM2
8
Shield (Clock)
AVI
20
CAM2
9
Clock
--
--
CAM2
10
not connected
--
--
CAM2
11
not connected
AVI
35
CAM2
12
Shield (Vd)
Note that this cable provides 12VDC (fused 1A max) to the cameras
from the Adept controller. The fuse is not user replaceable. If the total
current required by the two cameras exceeds 1A, this cable should
not be used.
