RTU -292 Operations Manual
1.3.4 OPTIONS
RTU-292 options include the: The Voice Prompt Option, which gives verbal prompts to the
user as an aid in all aspects of unit operation; The Local Phone Option, which allows a DTMF
telephone set to be plugged into the unit, allowing control and access from the phone set; and
the VMM-100 module, used to add VMR (Voice Modulation Recognition) and DSP noise
reduction capability. Among the Software Options are the Squelch Break Access Option,
which allows a radio to contact the system via series of squelch breaks and the DTMF Access
Option, which allows a radio user to contact the system via a DTMF keypad. Other Software
Options include Call Logging and Remote Control of an URC-200 radio. Various spares kits
are also available. The STU-III option allows a STU-III phone to be connected to the RTU-
292. This allows an encrypted STU-III conversation to be decrypted at the RTU-292. The
decrypted signal is patched into the connected radio system.
Table 1-2 Optional Equipment - Not Supplied
Item JPS P/N Description
Depot Spares Kit 5970-691000 Spares for 3 to 5 RTU-292s
Spare PC Board Kit 5970-692000 Spare Boards for 1 unit
Spare Parts Kit 5970-693000 Spares for one RTU-292
Local Phone Option 5930-596000 Allows remote operation of the RTU-292 through the use of
a standard telephone set connected directly to the RTU-292
Local Phone port. (Telephone set and cable not supplied.)
DTMF Telephone Set 5930-599000 Telephone set for use with the Local Phone Option
Voice Prompt Option 5930-595000 Standard Version (English, female voice)
VMM-100 Option 5930-591100 Provides DSP Voice Modulation Recognition squelch and/or
DSP Noise Reduction to the radio RX input.
STU-III Option 5960-796000 Allows connection to a STU-III phone
Rack Slides Kit 5930-594000 1 set slides and hardware to rack-mount one RTU-292.
Software Options
Call Logging S/W Option 5970-791500 Provides record of calls via RS-232 interface.
Radio Control Option 5970-795000 Provides remote control of URC-200 radio via RS-232 int.
Squelch Break Access 5970-791300 Allows radio connection via series of squelch breaks
DTMF Access Option 5970-799000 Allows radio connection via DTMF keypad.
JPS Communications, Inc. 1-5
