POWER WIRING INSTALLATION NOTES
062206
DESCRIPTION:
DATE:
DRAWING NO: SHEET:
REVISION:
C
164201546---4 9 of 10
INSTALLATION INFORMATION
EATON Powerware ® 9390 UPS Sidecar Installation and Operation Manual S 164201586 Rev E www.powerware.com A-25
15. Table O lists the maximum rating for rectifier input circuit breakers and Table P lists the
maximum rating for bypass input circuit breakers.
Table O. Maximum UPS Sidecar Rectifier Input Circuit Breaker Ratings
UPS Sidecar Model
Input Voltage Rating
208V 480V
40 kVA
80% Rated 175A 70A
100% Rated 150A 60A
50 kVA
80% Rated 225A 100A
100% Rated 175A 80A
60 kVA
80% Rated 250A 125A
100% Rated 200A 90A
80 kVA
80% Rated 350A 150A
100% Rated 300A 125A
100 kVA
80% Rated N/A 200A
100% Rated N/A 150A
120 kVA
80% Rated N/A 225A
100% Rated N/A 175A
160 kVA
80% Rated N/A 300A
100% Rated N/A 250A
Table P. Maximum UPS Sidecar Bypass Input Circuit Breaker Ratings
UPS Sidecar Model
Input Voltage Rating
208V 480V
40 kVA
80% Rated 175A 70A
100% Rated 150A 60A
50 kVA
80% Rated 225A 100A
100% Rated 175A 80A
60 kVA
80% Rated 250A 125A
100% Rated 200A 90A
80 kVA
80% Rated 350A 150A
100% Rated 300A 125A
100 kVA
80% Rated N/A 200A
100% Rated N/A 150A
120 kVA
80% Rated N/A 225A
100% Rated N/A 175A
160 kVA
80% Rated N/A 300A
100% Rated N/A 250A
C A U T I O N
To reduce the risk of fire, connect only to a circuit provided with
maximum input circuit breaker current ratings from Table O in accordance
with the NEC, ANSI/NFPA 70.
