INSTALLING THE UPS SIDECAR
EATON Powerware ® 9390 UPS Sidecar Installation and Operation Manual S 164201586 Rev E www.powerware.com 2-3
Front Panel
Front Panel
Attaching Screw
UPS Sidecar
UPS Cabinet
Figure 2-1. 80 kVA UPS with UPS Sidecar
