UPS SIDECAR FEATURES, CONTROLS, AND OPERATION
EATON Powerware ® 9390 UPS Sidecar Installation and Operation Manual S 164201586 Rev E www.powerware.com 4-8
Maintenance Bypass
Switch (MBP)
Maintenance Isolation
Switch (MIS)
Figure 4-5. UPS Sidecar Controls (Bypass) – 80/40, 80/50, 80/60, 80/80 kVA, 208/208V and
160/100, 160/120, and 160/160 kVA, 480/480V with MBP and MIS
