Patton electronic SmartNode 4830 Series - Manual (Page 73)

Operating environment 73
SmartNode 4830 Getting Started Guide B • Specifications
SNMP v1 agent (MIB II and private MIB)
Built-in diagnostic tools (trace, debug)
Java™ Applet; HPOV Integration with NNM
Operating environment
Operating temperature
32–104°F (0–40°C)
Operating humidity
5–80% (non condensing)
System
CPU Motorola MPC875 operating at 66 MHz
Memory:
• 32 Mbytes SDRAM
• 8 Mbytes Flash
Dimensions
7.3W x 1.6H x 6.1D in. (18.5H x 4.1W x 15.5D cm)
Weight and power dissipation
See table 17 .
Power supply
External power supply, 100–240 VAC, 50/60 Hz, 200 mA
Table 17. SmartNode weight and maximum power specifications
SmartNode model Weight Maximum power dissipation
SN4832/JSX/EUI 30.5 oz./500 g 7W
SN4834/JSX/EUI 30.5 oz./500 g 9W
SN4836/JSX/EUI 30.5 oz./500 g 11W
SN4838/JSX/EUI 30.5 oz./500 g 13W
