About this guide
This guide describes the SmartNode 4830 hardware, installation and basic configuration. For detailed software
configuration information refer to the
SmartWare Software Configuration Guide
and the available Configura-
tion Notes.
Audience
This guide is intended for the following users:
•
Operators
•
Installers
•
Maintenance technicians
Structure
This guide contains the following chapters and appendices:
•
on page 15 provides information about product features and capabilities
•
on page 25 contains an overview describing product operation and applications
•
on page 28 provides hardware installation procedures
•
on page 43 provides quick-start procedures for configuring the SmartNode product
•
on page 52 provides LED definitions
•
on page 56 provides information on configuring DSL
•
on page 61 contains information on contacting Patton technical support for assistance
•
on page 64 contains compliance information
•
on page 68 contains specifications for the products
•
on page 75 provides cable recommendations
•
on page 81 describes the product’s ports and pin-outs
•
on page 86 provides license information that describes acceptable usage of the software pro-
vided with the SmartNode 4830
•
on page 88 lists the cables that are available as accessories for the SmartNode 4900
Series products
For best results, read the contents of this guide
before
you install the product.
