Planning the installation
29
SmartNode 4830 Getting Started Guide
3 • Hardware installation
Planning the installation
Before you start the actual installation, we strongly recommend that you gather all the information you will
need to install and setup the device. See
for an example of what pre-installment checks you might need
to carry out. Completing the pre-installation checks enables you to install and set up your VoIP IAD within an
existing network infrastructure with confidence.
Note
When setting up your VoIP IAD you must consider cable-length lim-
itations, and potential electromagnetic interference (EMI) as defined
by the applicable local and international regulations. Ensure that your
site is properly prepared before beginning installation.
Before installing the VoIP IAD device, the following tasks should be completed:
•
Create a network diagram (see section
•
Gather IP related information (see section
on page 31 for more information)
•
Install the hardware and software needed to configure the SmartNode. (See section
•
Verify power source reliability (see section
When you finish preparing for your VoIP IAD installation, go to section
to install the device.
Mains Voltage: Do not open the case when the power cord is connected. For
systems without a power switch, line voltages are present within the power
supply when the power cord is connected. The mains outlet that is utilized to
power the SmartNode router shall be within 10 feet (3 meters) of the device,
shall be easily accessible, and protected by a circuit breaker.
WARNING
