7-5
MAX
Slide Rail
Adding Paper to the External LCF (Large Capacity Feeder) (optional)
1 Pull the external LCF out carefully until it comes to
a stop.
- Be careful not to touch the drawer slide rail.
2 Place the paper on the elevator tray.
- Place the paper face up.
- Maximum number of sheets that can be set Page 2-4
- Fan the paper well, then place it on the elevator tray, aligning
it on the rear guide tray.
- Set the paper so that it does not protrude beyond the line of
indication shown on the rear guide plate.
- Do not use creased, folded, wrinkled or damp sheets of
paper.
Do not touch the Elevator Tray while it is moving.
3 Close the cover of the external LCF.
- Close the cover completely. The elevator tray automatically
moves up to the paper feeding position.
Be careful not to let your fingers be caught when closing the
drawer.
Elevator Tray
