Preventative Maintenance Tests
Testing the Monitor 4-15
Documenting
NBP Test
Results The following table lists the tests that should be documented and summarizes how to
document the NBP test results.
Test Expected Test Results
What to record on
service record
Pressure Transducer Accuracy Test X1 = difference between the pressure on
the monitor and on the simulator
Difference less than or equal to 5
mmHg (0.7 kPa)
PN:P/X1/X2/X3/X4/X5
or
PN:F/X1/X2/X3/X4/X5
P = passed, F = failed Pneumatic Leakage Test X2 = difference between the pressure at
the start (P1) and after one minute (P2)
Difference less than or equal to 6
mmHg (0.8 kPa)
Inflation Rate Test X3 = number of seconds for the monitor
to inflate
Rate between 1 and 6 seconds
Over-Pressure Test X4 = peak value
Peak value between 270 and 330 mmHg
(36 kPa and 44 kPa)
Deflation Rate Test X5 = mmHg (kPa) per second to deflate
1.8 mmHg/s to 4.8 mmhg/s
