Diagnostic Mode
Configuring the Power-up Defaults Menu 5-9
Table 5-1. A/D Channel Designators
1. ECG
2. RWAVE
3. PACEMAKER
4. RESPIRATION
5. PRESSURE XDUCER 1
6. PRESSURE XDUCER 2
7. NBP OSCILLATORY
8. ECG LEAD OFF
9. TEMPERATURE
10. ISOLATED VOLTAGE REF
11. ISOLATED VOLTAGE ZERO
12. SpO
2
S1 S018
13. NOT USED
14. +3.3 VDC POWER SUPPLY
15. (+12 VDC POWER SUPPLY) x 0.33
16. (NBP VOLTAGE REF) x 0.8
17. GROUND REFERENCE
18. (+5 VDC POWER SUPPLY) x 0.8
19. ADC MID-SCALE VALUE
20. ADC ZERO-SCALE VALUE
21. ADC FULL-SCALE VALUE
