66 Diagnostic Test, Specifications
Diagnostic Test
If you are having trouble with the Recorder after checking Helpful Hints and other
information in this manual, try a Diagnostic Test.
1 Disconnect the power cord from the Recorder’s MAINS ~ (AC
Power) jack on the rear of the Recorder.
2 Press and hold the Play : button on the front of the Recorder
while you reconnect the power cord to the Recorder. “BUSY” will
appear on the display panel, along with a counter number. Release PLAY
:. The counter will reach zero (0) when the test is finished.
3 Momentarily, “FAIL” or “PASS” will appear on the display panel. If “FAIL”
appears, your Recorder needs repair. Contact the Philips Customer Care
Center for the Authorized Service Center nearest you.
If “PASS” appears, the Recorder apparently has no failure.The problem may
be incorrect interpretation of the operating instructions, a wrong Disc in
use, or incorrect connections. Contact the Philips Customer Care Center
for further assistance in solving the problem.
4 If there is no failure, disconnect the power cord again, then reconnect it to
the Recorder and an AC power outlet.The Recorder will be ready for use.
DVD+REWRITABLE DISC FORMAT
Medium Phase-Change ReWritable
Diameter 12 cm
Capacity (single side) 4.7 Gbyte
TV STANDARD PAL/SECAM NTSC
Scan Frequency 50Hz 60Hz
Number of lines 625 525
Play Yes Yes
Recording Yes Yes
Internal tuner No Yes
VIDEO FORMAT
Digital Compression MPEG2 for DVD, MPEG1 for VCD
REAR CONNECTIONS
Component Video Cinch (green/blue/red)
S-Video Hosiden 4-pin
Video (CVBS) Cinch (yellow)
Audio Left/Right Cinch (white/red)
Digital Audio Out 1 coaxial,1 optical
IEC958 for CDDA /LPCM
IEC1937 for MPEG2,
Dolby Digital
Antenna In,TV Out Coaxial 75 ohms
FRONT CONNECTIONS
DV IN CAM 2 IEEE 1394 4-pin
S-VIDEO IN Hosiden 4-pin
VIDEO and AUDIO IN Cinch (yellow, white, red)
AUDIO PERFORMANCE
DA Converter 24 bit
AD Converter 16 bit
DVD fs 96 kHz 4 Hz -44 kHz
fs 48 kHz 4 Hz -22 kHz
Video CD fs 44.1 kHz 4 Hz -20 kHz
Audio CD fs 44.1 kHz 4 Hz -20 kHz
Signal-Noise (1kHz) 105 dB
Dynamic Range (1kHz) 100 dB
Crosstalk (1kHz) 110 dB
Distortion/Noise (1kHz) 90 dB
AUDIO FORMAT
Compressed digital Play Recording
• Dolby Digital (AC-3) Multi-channel 2-channel
16 bit, fs 48 kHz
• DTS Multi-channel No
• MPEG1 2-channel No
• MPEG2 Multi-channel No
Uncompressed digital (SPDIF Sony Philips Digital Interface)
• PCM
2-channel No
16, 20, 24 bit
fs 48, 96 kHz
VIDEO PERFORMANCE
DA Converter 10-bit
AD Converter 9-bit
Signal handling Components
Video Out 1 Vpp into 75 Ohm
S-Video Out Y: 1 Vpp into 75 Ohm
C: 0.300 Vpp into 75 Ohm
Component Out Y: 1 Vpp into 75 Ohm
P
B
: 0.7 Vpp into 75 Ohm
P
R
: 0.7 Vpp into 75 Ohm
POWER SUPPLY
AC power polarized (IEC)
Power supply 110-130V/60 Hz
Power consumption Operation 29 W; Standby < 7 W
CABINET
Dimensions 17.2” W x 3.0” H x 13.2” D
Net weight 4.0 kg
Specifications
