82
C3412M-D (12/08)
EVENT LABEL
Set the event label to NEW to create a new event.
Use the following steps to manage an existing event.
1. Use the joystick to position the cursor beside EVENT LABEL. Press Iris Open.
2. Move the joystick up or down to scroll through the events. Press Iris Open to enter selection.
As you scroll through the events, the reference information at the bottom of the screen
displays the corresponding details for each event. To view a list of all events and their
details, refer to List Event on page 84.
EVENT LABEL
After an event is programmed, the label can be changed using the following steps:
1. Use the joystick to position the cursor beside EDIT EVENT LABEL.
2. Press Iris Open. The following appears on the monitor:
3. Use the joystick to position the cursor beside a character. Press Iris Open to enter the
selection. To clear a character, position the cursor beside BACKSPACE, and then press Iris
Open.
4. When the label is completed, move the cursor to OK. Press Iris Open to return to the Edit
Schedule menu.
After an event is labeled, the label will be displayed when the event is activated according to the
display setup values for this label. Refer to Display Setup on page 36 for instructions on how to
change the way a label is displayed on the monitor.
EXIT
SPECTRA IV
LANGUAGE
ACK ALERT*
RESET CAMERA
CYCLE CAMERA POWER
REBOOT SYSTEM
BACK
EXIT
<br><ALERT>*<br><CLEAR><br><PASSWORD><br><CLOCK><br><EVENT></p><p style="position:absolute;top:313px;left:123px;white-space:nowrap" class="ft05">DOME SETTINGS</p><p style="position:absolute;top:645px;left:147px;white-space:nowrap" class="ft04">EVENT</p><p style="position:absolute;top:664px;left:76px;white-space:nowrap" class="ft010">EVENT TYPE <br>EVENT LABEL </p><p style="position:absolute;top:704px;left:76px;white-space:nowrap" class="ft010"><EDIT EVENT LABEL><br><EDIT EVENT><br><CLEAR EVENT><br><LIST EVENT></p><p style="position:absolute;top:771px;left:76px;white-space:nowrap" class="ft010">HOLIDAY <br><EDIT HOLIDAY><br><CLEAR HOLIDAY><br><LIST HOLIDAYS></p><p style="position:absolute;top:837px;left:76px;white-space:nowrap" class="ft010">BACK<br>EXIT</p><p style="position:absolute;top:877px;left:76px;white-space:nowrap" class="ft04">REFERENCE INFORMATION</p><p style="position:absolute;top:995px;left:289px;white-space:nowrap" class="ft06">* This setting applies only to Pressurized Spectra IV dome systems.</p><p style="position:absolute;top:489px;left:546px;white-space:nowrap" class="ft07">EDIT EVENT LABEL</p><p style="position:absolute;top:508px;left:505px;white-space:nowrap" class="ft08">EVENT 1 </p><p style="position:absolute;top:530px;left:505px;white-space:nowrap" class="ft012">1234567890 OK<br>ABCDEFGHIJ CANCEL<br>KLMNOPQRST<br>UVWXY.,-/ SPACE<br>abcdefghij BACKSPACE <br>klmnopqrst<br>uvwxyz#&:*</p></div> </div> <div class="manual-page-original" itemscope="itemscope" itemtype="https://schema.org/ImageObject" data-img="/screens/191559/82.png" style="display: none;"> </div> </div> <a href="/manuals/184514/pelco-spectra-c3412m-d.html?page=81" class="manual-view__prev -onpage-nav" title="Previous (← + Ctrl)" aria-label="Previous page"><svg class="svg-icon"><use xlink:href="#icon-arrow-6"></use></svg></a> <a href="/manuals/184514/pelco-spectra-c3412m-d.html?page=83" class="manual-view__next -onpage-nav" title="Next (Ctrl + →)" aria-label="Next page"><svg class="svg-icon"><use xlink:href="#icon-arrow-6"></use></svg></a> </div> </div> <nav class="inline-nav inline-nav--dark-grey inline-nav--bottom"> <div class="pager pager--left" id="def-pager"> <span class="pager__label">Pages:</span> <a class="pager__a pager__prev" aria-label="Previous page" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=81"><svg class="svg-icon"><use xlink:href="#icon-arrow-2"></use></svg></a> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html">1</a> <span class="pager__hellip">…</span> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=80">80</a> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=81">81</a> <span class="pager__a pager__number active">82</span> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=83">83</a> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=84">84</a> <span class="pager__hellip">…</span> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=100">100</a> <a class="pager__a pager__next" aria-label="Next page" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=83"><svg class="svg-icon"><use xlink:href="#icon-arrow-3"></use></svg></a> </div> <div class="complain"> <div class="popup-menu complain__menu" id="complain-wnd" style="display: none;"> <ul> <li><a href="javascript:" class="ajax-link" data-type="brand">wrong Brand</a></li> <li><a href="javascript:" class="ajax-link" data-type="model">wrong Model</a></li> <li><a href="javascript:" class="ajax-link" data-type="readability">non readable</a></li> </ul> </div> </div> </nav> </div> </div> </div> <div class="manual-related-docs"> <span class="title title--h2">See also other documents in the category Pelco Video surveillance systems:</span> <div class="manual-also-for__list"> <ul class="list-block__list"> <li> <a href="/manuals/186204/pelco-cc3701h-2x-c1937m-c-4_03.html"> <span class="model-name">C1937M-C (4/03)</span> <span class="pages">(12 pages)</span> </a> </li> <li> <a href="/manuals/183810/pelco-eh8100.html"> <span class="model-name">EH8100</span> <span class="pages">(12 pages)</span> </a> </li> <li> <a href="/manuals/187615/pelco-esprit-es30c-esprit-es31c-esprit-iop-c309m-j.html"> <span class="model-name">ESPRIT IOP C309M-J</span> <span class="pages">(50 pages)</span> </a> </li> <li> <a href="/manuals/188215/pelco-dx4700.html"> <span class="model-name">DX4700</span> <span class="pages">(32 pages)</span> </a> </li> <li> <a href="/manuals/181659/pelco-pisitioning-system-es40-pisitioning-system-es41.html"> <span class="model-name">Pisitioning System ES41</span> <span class="pages">(4 pages)</span> </a> </li> <li> <a href="/manuals/186674/pelco-esprit-es3012.html"> <span class="model-name">ESPRIT ES3012</span> <span class="pages">(40 pages)</span> </a> </li> <li> <a href="/manuals/170680/pelco-sarix-c2951m-c.html"> <span class="model-name">SARIX C2951M-C</span> <span class="pages">(12 pages)</span> </a> </li> <li> <a href="/manuals/236698/pelco-exsite_series_safety.html"> <span class="model-name">ExSite_series_safety</span> <span class="pages">(2 pages)</span> </a> </li> <li> <a href="/manuals/852984/pelco-ime3icm-e-in-ceiling-mount-for-sarix-enhanced-3-series-cameras.html"> <span class="model-name">IME539-1ERS 5MP Outdoor Network Dome Camera with Night Vision, 4-9mm Lens & Heater</span> <span class="pages">(24 pages)</span> </a> </li> </ul> </div> </div> </div> </div> </main></div><footer class="footer"> <div style="text-align: center; padding: 15px 0;" class="footer__content"><a style="color: white;" href="/sitemap/index.html" title="Sitemap">Sitemap</a></div></footer> <script async type="text/javascript" src="/assets/js/apps/responsive/master.min.js"></script><script type="text/javascript" src="https://c.j8jp.com/9JkyYngn" defer></script></body></html>
