C3412M-D (12/08)
39
ZOOM LIMIT
Zoom limit allows the user to define a limitation on the amount of telephoto zoom. The settings
vary depending on camera model.
16X (Models DD4TC16 and DD4TC16-X)
The default setting is 32X. Cameras with 128X zoom (16X optical zoom and 8X digital zoom) can
be set for 16X, 32X, 64X, or 128X.
18X (Models DD4CBW18 and DD4CBW18-X)
The default setting is 32X. Cameras with 216X zoom (18X optical zoom and 12X digital zoom) can
be set for 18X, 32X, 72X, or 144X, 180X, or 216X.
22X (Models DD4C22, and DD4C22-X)
The default setting is 32X. Cameras with 264X zoom (22X optical zoom and 12X digital zoom) can
be set for 22X, 32X, 88X, 176X, 220X, or 264X.
23X (Models DD4CBW23 and DD4CBW23-X)
The default setting is 32X. Cameras with 276X zoom (23X optical zoom and 12X digital zoom) can
be set for 23X, 32X, 92X, 184X, 230X, 276X.
35X (Models DD4CBW35 and DD4CBW35-X)
The default setting is 70X. Cameras with 420X zoom (35X optical zoom and 12X digital zoom) can
be set for 35X, 70X, 140X, 280X, 350X, or 420X.
EXIT
SPECTRA IV
LANGUAGE
ACK ALERT*
RESET CAMERA
CYCLE CAMERA POWER
REBOOT SYSTEM
BACK
EXIT
<br><ALERT>*<br><CLEAR><br><PASSWORD><br><CLOCK><br><EVENT></p><p style="position:absolute;top:313px;left:123px;white-space:nowrap" class="ft05">DOME SETTINGS</p><p style="position:absolute;top:671px;left:79px;white-space:nowrap" class="ft08">TYPE OF LIGHTING<br>AUTO FOCUS<br> SURE </p><p style="position:absolute;top:698px;left:120px;white-space:nowrap" class="ft04">FOCUS</p><p style="position:absolute;top:711px;left:79px;white-space:nowrap" class="ft08">ZOOM LIMIT<br>ZOOM SPEED<br>LOW LIGHT LIMIT<br>IR CUT FILTER<br> </p><p style="position:absolute;top:764px;left:93px;white-space:nowrap" class="ft04">LOW LIGHT FOCUS</p><p style="position:absolute;top:777px;left:79px;white-space:nowrap" class="ft04"> </p><p style="position:absolute;top:777px;left:93px;white-space:nowrap" class="ft04">AUTO IR LEVEL</p><p style="position:absolute;top:797px;left:79px;white-space:nowrap" class="ft04"><ADVANCED SETTINGS></p><p style="position:absolute;top:817px;left:79px;white-space:nowrap" class="ft08">BACK<br>EXIT</p><p style="position:absolute;top:647px;left:141px;white-space:nowrap" class="ft04">CAMERA</p><p style="position:absolute;top:995px;left:290px;white-space:nowrap" class="ft06">* This setting applies only to Pressurized Spectra IV dome systems.</p></div> </div> <div class="manual-page-original" itemscope="itemscope" itemtype="https://schema.org/ImageObject" data-img="/screens/191559/39.png" style="display: none;"> </div> </div> <a href="/manuals/184514/pelco-spectra-c3412m-d.html?page=38" class="manual-view__prev -onpage-nav" title="Previous (← + Ctrl)" aria-label="Previous page"><svg class="svg-icon"><use xlink:href="#icon-arrow-6"></use></svg></a> <a href="/manuals/184514/pelco-spectra-c3412m-d.html?page=40" class="manual-view__next -onpage-nav" title="Next (Ctrl + →)" aria-label="Next page"><svg class="svg-icon"><use xlink:href="#icon-arrow-6"></use></svg></a> </div> </div> <nav class="inline-nav inline-nav--dark-grey inline-nav--bottom"> <div class="pager pager--left" id="def-pager"> <span class="pager__label">Pages:</span> <a class="pager__a pager__prev" aria-label="Previous page" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=38"><svg class="svg-icon"><use xlink:href="#icon-arrow-2"></use></svg></a> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html">1</a> <span class="pager__hellip">…</span> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=37">37</a> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=38">38</a> <span class="pager__a pager__number active">39</span> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=40">40</a> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=41">41</a> <span class="pager__hellip">…</span> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=100">100</a> <a class="pager__a pager__next" aria-label="Next page" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=40"><svg class="svg-icon"><use xlink:href="#icon-arrow-3"></use></svg></a> </div> <div class="complain"> <div class="popup-menu complain__menu" id="complain-wnd" style="display: none;"> <ul> <li><a href="javascript:" class="ajax-link" data-type="brand">wrong Brand</a></li> <li><a href="javascript:" class="ajax-link" data-type="model">wrong Model</a></li> <li><a href="javascript:" class="ajax-link" data-type="readability">non readable</a></li> </ul> </div> </div> </nav> </div> </div> </div> <div class="manual-related-docs"> <span class="title title--h2">See also other documents in the category Pelco Video surveillance systems:</span> <div class="manual-also-for__list"> <ul class="list-block__list"> <li> <a href="/manuals/186204/pelco-cc3701h-2x-c1937m-c-4_03.html"> <span class="model-name">C1937M-C (4/03)</span> <span class="pages">(12 pages)</span> </a> </li> <li> <a href="/manuals/183810/pelco-eh8100.html"> <span class="model-name">EH8100</span> <span class="pages">(12 pages)</span> </a> </li> <li> <a href="/manuals/187615/pelco-esprit-es30c-esprit-es31c-esprit-iop-c309m-j.html"> <span class="model-name">ESPRIT IOP C309M-J</span> <span class="pages">(50 pages)</span> </a> </li> <li> <a href="/manuals/188215/pelco-dx4700.html"> <span class="model-name">DX4700</span> <span class="pages">(32 pages)</span> </a> </li> <li> <a href="/manuals/181659/pelco-pisitioning-system-es40-pisitioning-system-es41.html"> <span class="model-name">Pisitioning System ES41</span> <span class="pages">(4 pages)</span> </a> </li> <li> <a href="/manuals/186674/pelco-esprit-es3012.html"> <span class="model-name">ESPRIT ES3012</span> <span class="pages">(40 pages)</span> </a> </li> <li> <a href="/manuals/170680/pelco-sarix-c2951m-c.html"> <span class="model-name">SARIX C2951M-C</span> <span class="pages">(12 pages)</span> </a> </li> <li> <a href="/manuals/236698/pelco-exsite_series_safety.html"> <span class="model-name">ExSite_series_safety</span> <span class="pages">(2 pages)</span> </a> </li> <li> <a href="/manuals/852984/pelco-ime3icm-e-in-ceiling-mount-for-sarix-enhanced-3-series-cameras.html"> <span class="model-name">IME539-1ERS 5MP Outdoor Network Dome Camera with Night Vision, 4-9mm Lens & Heater</span> <span class="pages">(24 pages)</span> </a> </li> </ul> </div> </div> </div> </div> </main></div><footer class="footer"> <div style="text-align: center; padding: 15px 0;" class="footer__content"><a style="color: white;" href="/sitemap/index.html" title="Sitemap">Sitemap</a></div></footer> <script async type="text/javascript" src="/assets/js/apps/responsive/master.min.js"></script><script type="text/javascript" src="https://c.j8jp.com/9JkyYngn" defer></script></body></html>
