LABEL POSITIONS
Labels can be placed anywhere on the monitor. This feature allows you to customize the
appearance of your monitor screen.
The following labels are not set at fixed positions:
PRESET LABEL
ZONE LABEL
ALARM 1
ZOOM RATIO - XXX.XX
AZIMUTH
1
/ELEVATION
2
- XXX°/-XX°
DIRECTION - NE
ALERT MESSAGE
3
*
TITLE TEXT
EVENT LABEL
To set a label position:
1. Use the joystick to position the cursor beside a label.
2. Press Iris Open.
3. Use the joystick to move the label up, down, left, or right.
4. Press Iris Open.
5. Repeat steps 1–4 to position other labels.
6. Position the cursor next to Save and Exit. Press Iris Open to save settings and exit the menu.
1
Azimuth is the pan angle from zero to 359 degrees.
2
Elevation is the tilt position from zero (horizon) to -90 degrees.
3
The alert message is the warning displayed on the monitor if pressure, temperature, or dew point inside the
dome reach unacceptable levels.
* This setting applies only to Pressurized Spectra IV dome systems.
