48
C3412M-D (12/08)
IMAGE ENHANCEMENT
(Applies only to 35X models.)
The image enhancement feature improves the definition of objects, lines, or text in high contrast
areas, making them appear sharper.
There are two image enhancement settings:
DEFAULT: Image enhancement is not activated.
ENHANCED: Image enhancement is activated.
LOW LUX NOISE REDUCTION
(Applies only to 18X and 23X models.)
Low lux noise reduction helps to reduce video noise in low light scenes. When enabled, low lux
noise reduction is directly affected by the AGC settings for the dome system.
The following are the low lux noise reduction settings:
ON (default): Low lux noise reduction is enabled. As the scene darkens and AGC increases, the
noise reduction effect automatically increases. As noise reduction increases, you may also notice
some afterimaging and a slight reduction in color saturation.
OFF: Low lux noise reduction is disabled.
Warning: When using this feature be aware that picture noise, although unnoticeable to
the eye, will increase and may cause compression rate changes in DVRs, NVRs, and
network devices.
EXIT
SPECTRA IV
LANGUAGE
ACK ALERT*
RESET CAMERA
CYCLE CAMERA POWER
REBOOT SYSTEM
BACK
EXIT
<br><ALERT>*<br><CLEAR><br><PASSWORD><br><CLOCK><br><EVENT></p><p style="position:absolute;top:271px;left:123px;white-space:nowrap" class="ft06">DOME SETTINGS</p><p style="position:absolute;top:569px;left:80px;white-space:nowrap" class="ft012">TYPE OF LIGHTING<br>AUTO FOCUS<br> SURE </p><p style="position:absolute;top:591px;left:121px;white-space:nowrap" class="ft07">FOCUS</p><p style="position:absolute;top:602px;left:80px;white-space:nowrap" class="ft012">ZOOM LIMIT<br>ZOOM SPEED<br>LOW LIGHT LIMIT<br>IR CUT FILTER<br> </p><p style="position:absolute;top:645px;left:93px;white-space:nowrap" class="ft07">LOW LIGHT FOCUS</p><p style="position:absolute;top:656px;left:80px;white-space:nowrap" class="ft07"> </p><p style="position:absolute;top:656px;left:93px;white-space:nowrap" class="ft07">AUTO IR LEVEL</p><p style="position:absolute;top:672px;left:80px;white-space:nowrap" class="ft07"><ADVANCED SETTINGS></p><p style="position:absolute;top:688px;left:80px;white-space:nowrap" class="ft012">BACK<br>EXIT</p><p style="position:absolute;top:550px;left:142px;white-space:nowrap" class="ft07">CAMERA</p><p style="position:absolute;top:965px;left:76px;white-space:nowrap" class="ft013">BACK<br>EXIT</p><p style="position:absolute;top:746px;left:112px;white-space:nowrap" class="ft08">ADVANCED SETTINGS</p><p style="position:absolute;top:767px;left:76px;white-space:nowrap" class="ft014">SHUTTER SPEED <br>AGC LIMIT <br>AUTO IRIS <br> AUTO IRIS LEVEL <br> AUTO IRIS PEAK <br>AUTO SHARPNESS <br> SHARPNESS LEVEL <br>AUTO WHITE BALANCE <br> R GAIN <br> B GAIN <br>BACKLIGHT COMP <br>VIDEO LEVEL <br>SENSOR SCAN MODE<br> FIELD ALIGN<br>E. IMAGE STABILIZER<br>IMAGE ENHANCEMENT<br>LOW LUX NOISE REDUCTION<br>WIDE DYNAMIC RANGE </p></div> </div> <div class="manual-page-original" itemscope="itemscope" itemtype="https://schema.org/ImageObject" data-img="/screens/191559/48.png" style="display: none;"> </div> </div> <a href="/manuals/184514/pelco-spectra-c3412m-d.html?page=47" class="manual-view__prev -onpage-nav" title="Previous (← + Ctrl)" aria-label="Previous page"><svg class="svg-icon"><use xlink:href="#icon-arrow-6"></use></svg></a> <a href="/manuals/184514/pelco-spectra-c3412m-d.html?page=49" class="manual-view__next -onpage-nav" title="Next (Ctrl + →)" aria-label="Next page"><svg class="svg-icon"><use xlink:href="#icon-arrow-6"></use></svg></a> </div> </div> <nav class="inline-nav inline-nav--dark-grey inline-nav--bottom"> <div class="pager pager--left" id="def-pager"> <span class="pager__label">Pages:</span> <a class="pager__a pager__prev" aria-label="Previous page" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=47"><svg class="svg-icon"><use xlink:href="#icon-arrow-2"></use></svg></a> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html">1</a> <span class="pager__hellip">…</span> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=46">46</a> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=47">47</a> <span class="pager__a pager__number active">48</span> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=49">49</a> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=50">50</a> <span class="pager__hellip">…</span> <a class="pager__a pager__number" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=100">100</a> <a class="pager__a pager__next" aria-label="Next page" href="/manuals/184514/pelco-spectra-c3412m-d.html?page=49"><svg class="svg-icon"><use xlink:href="#icon-arrow-3"></use></svg></a> </div> <div class="complain"> <div class="popup-menu complain__menu" id="complain-wnd" style="display: none;"> <ul> <li><a href="javascript:" class="ajax-link" data-type="brand">wrong Brand</a></li> <li><a href="javascript:" class="ajax-link" data-type="model">wrong Model</a></li> <li><a href="javascript:" class="ajax-link" data-type="readability">non readable</a></li> </ul> </div> </div> </nav> </div> </div> </div> <div class="manual-related-docs"> <span class="title title--h2">See also other documents in the category Pelco Video surveillance systems:</span> <div class="manual-also-for__list"> <ul class="list-block__list"> <li> <a href="/manuals/186204/pelco-cc3701h-2x-c1937m-c-4_03.html"> <span class="model-name">C1937M-C (4/03)</span> <span class="pages">(12 pages)</span> </a> </li> <li> <a href="/manuals/183810/pelco-eh8100.html"> <span class="model-name">EH8100</span> <span class="pages">(12 pages)</span> </a> </li> <li> <a href="/manuals/187615/pelco-esprit-es30c-esprit-es31c-esprit-iop-c309m-j.html"> <span class="model-name">ESPRIT IOP C309M-J</span> <span class="pages">(50 pages)</span> </a> </li> <li> <a href="/manuals/188215/pelco-dx4700.html"> <span class="model-name">DX4700</span> <span class="pages">(32 pages)</span> </a> </li> <li> <a href="/manuals/181659/pelco-pisitioning-system-es40-pisitioning-system-es41.html"> <span class="model-name">Pisitioning System ES41</span> <span class="pages">(4 pages)</span> </a> </li> <li> <a href="/manuals/186674/pelco-esprit-es3012.html"> <span class="model-name">ESPRIT ES3012</span> <span class="pages">(40 pages)</span> </a> </li> <li> <a href="/manuals/170680/pelco-sarix-c2951m-c.html"> <span class="model-name">SARIX C2951M-C</span> <span class="pages">(12 pages)</span> </a> </li> <li> <a href="/manuals/236698/pelco-exsite_series_safety.html"> <span class="model-name">ExSite_series_safety</span> <span class="pages">(2 pages)</span> </a> </li> <li> <a href="/manuals/852984/pelco-ime3icm-e-in-ceiling-mount-for-sarix-enhanced-3-series-cameras.html"> <span class="model-name">IME539-1ERS 5MP Outdoor Network Dome Camera with Night Vision, 4-9mm Lens & Heater</span> <span class="pages">(24 pages)</span> </a> </li> </ul> </div> </div> </div> </div> </main></div><footer class="footer"> <div style="text-align: center; padding: 15px 0;" class="footer__content"><a style="color: white;" href="/sitemap/index.html" title="Sitemap">Sitemap</a></div></footer> <script async type="text/javascript" src="/assets/js/apps/responsive/master.min.js"></script><script type="text/javascript" src="https://c.j8jp.com/9JkyYngn" defer></script></body></html>
