Installing the input module

Types of the input modules (optional)

Prepare beforehand an input module (optional) compatible with the input signals of the system.

*1: The LAN terminal of the input module (optional) cannot be used with the PT-D10000E/PT-DW10000E. Use the

LAN terminal that is provided as standard with the projector.

*2: HDCP (High-bandwidth Digital Content Protection)

HDCP is a specification for encoding digital image signals which was developed to protect digital content.
The DVI-D/HDMI output signals from the HDCP-compliant equipment have been encoded by the HDCP
specifications to ensure content protection, but the DVI-D input module is capable of displaying the digital
images properly since it complies with the HDCP specification.

Module

Module model

No.

Terminal

Signal formats supported

SD-SDI
input module

ET-MD77SD1

BNC input × 1
BNC output × 1

SMPTE259M compliant : 480i, 576i

RJ-45 input × 1

*1

10BASE-T/100BASE-TX

HD/SD-SDI
input module

ET-MD77SD3

BNC input × 1
BNC output × 1

SMPTE259M compliant : 480i, 576i
SMPTE292M compliant :

720/60p, 720/59.94p, 720/50p
1 035/60i, 1 035/59.94i, 1 080/60i, 1 080/59.94i
1 080/50i, 1 080/24sF, 1 080/23.98sF, 1 080/30p
1 080/29.97p, 1 080/25p, 1 080/24p, 1 080/23.98p

RJ-45 input × 1

*1

10BASE-T/100BASE-TX

DVI-D
input module

ET-MD77DV

DVI-D 24p
input × 1

HDCP-compliant

*2

DVI-D single link, DVI 1.0 compliant

EDID1 :

480p, 576p, 720/60p, 720/59.94p, 720/50p
1 080/60i, 1 080/59.94i, 1 080/50i, 1 080/24sF,
1 080/23.98sF
1 080/30p, 1 080/29.97p, 1 080/25p, 1 080/24p,
1 080/23.98p, 1 080/50p, 1 080/59.94p, 1 080/60p

EDID2 :

Displayable resolution VGA - UXGA (non-interlace)
Dot clock frequency 25 - 162 MHz

RJ-45 input × 1

*1

10BASE-T/100BASE-TX

Module

Module model

No.

Terminal

Signal formats supported

SD-SDI
input module

ET-MD77SD1

BNC input × 1
BNC output × 1

SMPTE259M compliant : 480i, 576i

RJ-45 input × 1

*1

10BASE-T/100BASE-TX

HD/SD-SDI
input module

ET-MD77SD3

BNC input × 1
BNC output × 1

SMPTE259M compliant : 480i, 576i
SMPTE292M compliant :

720/60p, 720/59.94p, 720/50p
1 035/60i, 1 035/59.94i, 1 080/60i, 1 080/59.94i
1 080/50i, 1 080/24sF, 1 080/23.98sF, 1 080/30p
1 080/29.97p, 1 080/25p, 1 080/24p, 1 080/23.98p

RJ-45 input × 1

*1

10BASE-T/100BASE-TX

DVI-D
input module

ET-MD77DV

DVI-D 24p
input × 1

HDCP-compliant

*2

DVI-D single link, DVI 1.0 compliant

EDID1 :

480p, 576p, 720/60p, 720/59.94p, 720/50p
1 080/60i, 1 080/59.94i, 1 080/50i, 1 080/24sF,
1 080/23.98sF
1 080/30p, 1 080/29.97p, 1 080/25p, 1 080/24p,
1 080/23.98p, 1 080/50p, 1 080/59.94p, 1 080/60p

EDID2 :

Displayable resolution VGA - UXGA (non-interlace)
Dot clock frequency 25 - 162 MHz

RJ-45 input × 1

*1

10BASE-T/100BASE-TX
