91

RQT9428

Con

venient

functions

PCM Down Conversion

Select how to output audio with a sampling frequency of 96 kHz.

It will be converted to 48 kHz regardless of the setting in

following cases.

The signals have a sampling frequency of over 96 kHz.

The disc has copy protection.

“BD-Video Secondary Audio” is set to “On”. (

BD-V

)

[On]

Signals are converted to 48 kHz. (Choose when

the connected equipment cannot process signals

with a sampling frequency of 96 kHz.)

[Off]

Signals are output as 96 kHz. (Choose when the

connected equipment can process signals with a

sampling frequency of 96 kHz.)

Dolby D/Dolby D +/Dolby TrueHD

1

DTS/DTS-HD

2

MPEG

1

Select to output Dolby Digital, Dolby Digital plus, Dolby TrueHD,

DTS Digital surround, DTS-HD High Resolution Audio, DTS HD

Master Audio or MPEG as bitstream or PCM.

Note

Not making the proper settings may result in noise.

If the unit is connected with the HDMI AV OUT terminal, the

specifi cations of the connected equipment take preference

over this unit and audio selected in these items may not be

output (e.g., when a television is connected, the HDMI audio

output of this unit is limited to down-mixed 2ch.)

[Bitstream]

Select “Bitstream” when the connected

equipment can decode the respective audio

format.

– Connect equipment supporting HDMI Ver. 1.3

and use a High Speed HDMI Cable in order to

output high bit rate audio such as Dolby

Digital Plus, Dolby TrueHD, DTS-HD High

Resolution Audio or DTS-HD Master Audio.

[PCM]

Select “PCM” when the connected equipment

cannot decode the respective audio format.

Refer to the operating instructions for connected

devices to verify whether or not they can decode

each of the audio formats.

Set the speaker output on the amplifi er when

output with PCM.

1

The default setting is “PCM”.

2

The default setting is “Bitstream”.

BD-Video Secondary Audio

(

BD-V

with secondary audio)

Turn on/off the clicking sound on the menu and audio with

secondary video.
[On]

The sampling frequency is converted to 48kHz.

Audio will be converted to Dolby Digital or DTS

during playback of the BD-Video with secondary

audio when “Bitstream” (

➡ above) is selected.

[Off]

Output in original audio method.

Audio Mode for XP Recording

Choose the audio type when recording or copying with XP mode.
[Dolby Digital] (

➡ 118)

[LPCM] (

➡ 118)

The picture quality of LPCM recordings may be lower than that

of normal XP mode recordings.

The audio recording becomes Dolby Digital even if you selected

LPCM when using a recording mode other than XP.

When recording a bilingual broadcast, select the type of audio

in advance from “Bilingual Audio Selection” (

➡ 90).

Audio Mode for DV Input

You can select the kind of audio when recording from the unit’s

DV input terminal (

➡ 58).

[Stereo 1]

Records audio (L1, R1).

[Stereo 2]

Records added audio such as narration (L2, R2)

subsequent to original recording.

[Mix]

Records both Stereo 1 and Stereo 2.

When recording bilingual broadcast, select the type of audio in

advance from “Bilingual Audio Selection” (

➡ 90).

Audio Mode for Digital Broadcast

Selects the initial setting for Audio tracks.

If programme has both Dolby Digital and MPEG audio tracks,

priority is given to what you select.

Only the selected audio is recorded when recorded or copied in

HG, HX, HE, HL, XP, SP, LP, EP or FR recording mode.

(It is recorded in accordance with the setting of “Audio Selection”

in the Disc menu only when it is copied with “Copy Title Playing”.)
[Dolby Digital]

A method of coding digital signals developed by

Dolby Laboratories. Apart from stereo (2ch)

audio, these signals can also be multi-channel

audio.

[MPEG]

An audio compression method that compresses

audio to small size without any considerable

loss of audio quality.

Audio Channels for HG/HX/HE/HL Recording

This will set the audio when recording to the HDD in HG, HX, HE

or HL modes, or converting the recording mode (

➡ 48).

[5.1-channel]

Record using 5.1 ch audio

[2-channel]

Record using 2 ch audio.

If the audio sampling frequency is not 48 kHz, surround audio is

mixed and recorded in front LR channels. Audio will be output

from two front speakers only, even if you play it on 5.1 ch

speaker connection.

Display

(All factory default settings are indicated with underlined text.)

On-Screen Messages

Choose the approximate time until the digital channel information

screen (

➡ 21) disappears automatically.

The length of time the control panel (

➡ 79) is displayed can also

be changed, but “Off” does not work.
[Off] (The digital channel information is not displayed.)
[3 sec.]

[5 sec.]

[7 sec.]

[10 sec.]

Unit’s Display

Changes the brightness of the unit’s display.

This setting is fi xed with “Automatic” if you set “Power Save”

(

➡ 94) to “On”, and is changed to “Bright” if you set “Power Save”

to “Off”.
[Bright]

[Dim]

[Automatic]

The display turns dark during play and disappears

when the unit is turned off. It reappears

momentarily if a button is pressed. While using this

mode, the standby power consumption can be

reduced.

Screen Saver

This is to prevent burn-in on the screen.

When this is set to “On”, the masked-off area on the screen

becomes grey.

[Only when connecting with an HDMI cable or a component

video cable and “HDMI Video Format” (

➡ 92) is set to any other

mode than “576p/480p”, or “Component Resolution” (

➡ 93) is

set to “720p” or “1080i”]

[On]

If there is no operation for 10 minutes or more, the

displayed screen switches to the other states

automatically.

– When the Direct Navigator, TV Guide, Timer

recording list, Copying list, DELETE Navigator

or FUNCTION menu is displayed, the display on

the screen is not displayed.

– When Music is played, the display returns to the

screen saver mode. (Playback continues.)

– When still pictures are shown (except for

slideshows), the display returns to the Direct

Navigator screen.

– The display returns to the screen saver mode

when it is paused by the Pause Live TV. (Pause

status will continue.)

[Off]

Teletext

Select the Teletext display mode. (

➡ 21)

[TOP (FASTEXT)]
[List]
