Adding Fixed Alphanumeric Text
231
The last two commands have added to the form definition. PRACTICE
now looks like Figure 51.
Figure 51 . Box/Corner Example with Horizontal and Vertical Lines
Adding Fixed Alphanumeric Text
10. Use the Create Form mode Alpha command to add some fixed
alphanumeric text to the form. Specify some compressed print (C n), the
starting row ( SR) and starting column (SC) for each alphanumeric string,
any vertically ( VE) or horizontally (HE) expanded strings, and the
alphanumeric string itself which must be within the printable character
(quotation marks or asterisks, for example). Substitute your own name,
address, etc. in the appropriate areas. If you do not want to include some
of the data on your form, do not enter the line.
Enter Format
ALPHA ALPHA
31;22;0;0;*ACME MOTOR, INC.* [R;][E;][C n;][AFn;L;][DIR;][UC;][DARK]
SR;SC;VE;HE;(D)Text(D)
32;22;0;0;*17500 CARTWRIGHT ROAD*
33;22;0;0;*IRVINE, CA 92714*
35.9;17;0;0;*SERIAL NUMBER*
40.3;17;0;0;*PART NUMBER*
40.3;50;0;0;*MFG. DATE*
45.3;17;0;0;*DESCRIPTION*
49.3;17;0;0;*INTERFACE*
49.3;50;0;0;*VERSION*
C13;31;16;0;0;*FROM:*
C15;54;26;0;0;*
Call ACME MOTOR for more information. *
C15;55;34;0;0;* 1(714)863-1900 *
STOP STOP
COLUMN 49
ROW 40
ROW 45
ROW 49
