Pioneer Plasma Display Monitor 502MX User Manual
Page 65
65
Tiltable Plasma Display Wall-Mount Hardware: PDK-5006
4.7 Tiltable Plasma Display Wall-Mount Hardware: PDK-5006
4.7.1 Specifications
External dimensions ................. 1218 (W)
×
125 (D)
×
714 (H) mm
Weight ....................................... 7.6 kg (mounting hardware only)
47.9 kg (mounting hardware and plasma display)
Materials .................................... General structural steel tubes (STK-MR)
Finish .......................................... Semi-matte black paint on rear (Original Pioneer color)
Dimensions of packaging ......... 1185 (W)
×
270 (D)
×
80 (H) mm
Package weight ......................... 8.6kg
Accessories
Vertical frame (left and right) ...............................
×
2
Horizontal frame ..................................................
×
2
Hexagonal socket head flange bolt .....................
×
8
Monitor fastening bolt (with washer) ..................
×
8
Washer ................................................................
×
4
Hexagonal wrench ..............................................
×
1
In wall-mounting installation allow adequate space (a clearance of 300 mm or more) above and below the monitor set,
as well as on the right and the left.
✩ Operating Temperature Restrictions
• Ambient temperature:
0 to 40 °C
✩ Operating Temperature Restrictions for Upside-Down Installations
* Upside-Down Installation is unavailable with the PDK-5006.
✩ Operating temperature restrictions for when the speaker system (PDP-S03-LR) is attached.
• Ambient temperature:
0 to 40 °C
