56
200 300
200
300
4 -
φ
13.5 × 22
φ
60.5
1218
45°
45°
R658
R617
This circle shows the path that the outermost part
of the plasma display follows when it is rotated
about a vertical axis after having been tilted
sideways by 25°. (Without optional speaker.)
255 102
51 118
805
1162
φ
240.5
φ
70
4.5.2 External Dimensions
Unit: mm
Plasma Ceiling Suspension Hardware (one-side type): PDK-5002
25°
12.2
This circle shows the path that the outermost part
of the plasma display follows when it is rotated
about a vertical axis after having been tilted
sideways by 25°. (Without optional speaker.)
