Pioneer Plasma Display Monitor 502MX - Manual (Page 125)

125
15) Initializing Adjustments (ALL DEFAULT)
You can restore items adjusted in the integrator mode to their factory-preset values.
You can reset all of the PICTURE, WHITE BALANCE and SCREEN adjustment values (refer to 5.4.3 1), 2) and 3)) to
their factory preset values in one go.
1 Before entering integrator mode, switch the unit to the input
(INPUTs 1 to 4) with the parameters which you want to
return to their original settings (refer to section 5.4.1, “About
the integrator mode”).
For initialization, use input signals that would be used in an
actual production run.
Make sure that the current color mode is set to the mode in
which you want to restore parameters to factory presets
(refer to section 5.4.3, 5)).
The ID number of the unit of items will be indicated in the
upper right corner of the screen, where “– –” is displayed
in the illustration.
Select DEFAULT.
2 Move the cursor to “YES” using the 2 button on the remote
control or the operating panel of the main unit, and press the
SET button. This restores the following parameters to their
factory-pre-set values, and returns the unit to screen 1.
• PICTURE parameters: refer to section 5.4.3, 1)
• WHITE BALANCE parameters: refer to section 5.4.3, 2)
• SCREEN parameters: refer to section 5.4.3, 3)
Move the cursor to “NO” and press the SET button to return to screen 1 with remaining the adjustment values.
(NOTE) The following items may not be initialized.
Integrator mode:
• SIDE MASK
• OPTION 1 (all)
• OPTION 2 (all)
• SUB VOLUME
Menu mode:
• POWER SAVE
• SETUP (all)
WHITE BAL.
MENU
SCREEN
SIDE MASK
OPTION 1
OPTION 2
SUB VOLUME
3ALL DEFAULT
– –
Integrator Mode
ALL DEFAULT – –
ALL DEFAULT ?
YES 2 3 NO
]
Screen 1
]
Screen 2
