Specifications
2.1 Specifications
Light-emitting panel .................. 50-inch plasma display panel
Aspect ratio .................................................................... 16 : 9
PEL .......................................................................... 1280
×
768
PEL pitch ........................... 0.858 (H•RGB trio)
×
0.808 (V) mm
Gradation ..................................... 256/16.77 million full colors
Viewing angle .................. Horizontal: more than 160 degrees
Vertical: more than 160 degrees
Video-related
Input/output terminals
INPUT 1 Input BNC terminal
Composite video signal
........................ 1 Vp-p/75
Ω
/sync negative
Output BNC terminal ................... 75 Ω /with buffer
INPUT 2 Input 1 S terminal (Mini-DIN, 4-pin connector)
(NOTE 1) 2 BNC terminal × 2
Y/C separate video signal (for S2)
Y ...... 1 Vp-p/75 Ω /sync negative
C ...... 0.286 Vp-p/75
Ω
(NTSC)
0.3 Vp-p/75
Ω
(PAL)
INPUT 3 Input BNC terminal
×
5
1 RGB signal (for G ON SYNC)
R,G,B ............ 0.7 Vp-p/75 Ω /no sync
G ON SYNC .. 1 Vp-p/75
Ω
/
sync negative
HD/CS.VD TTL level (1 to 5 Vp-p)/
positive and
negative polarity/
75
Ω
or 2.2 k
Ω
(with
impedance switching)
2 Component video signal
Y ......... 1.0 Vp-p/75
Ω
/sync negative
P B /C B , P R /C R ... 0.525 Vp-p/75
Ω
(75% degree of saturation)
INPUT 4 Input Mini D-sub, 15-pin connector (female)
1 RGB signal (for G ON SYNC)
R,G,B ............ 0.7 Vp-p/75
Ω
/no sync
G ON SYNC .. 1 Vp-p/75
Ω
/
sync negative
HD/CS.VD TTL level (1 to 5 Vp-p)/
positive and
negative polarity/
2.2 k
Ω
2 Component video signal
Y ........ 1.0 Vp-p/75
Ω
/sync negative
P B /C B , P R /C R ............ 0.525 Vp-p/75
Ω
.......... (75% degree of saturation)
* Microsoft Plug & Play (VESA DDC 1/2B) supported
Output Mini D-sub, 15-pin connector (female)
.......... 75
Ω
/with buffer
Audio-related
AUDIO INPUT Input Pin jack (
×
2)
(for INPUT 1/2) L/R .... above 500 mVrms/10 k
Ω
AUDIO INPUT Input Stereo mini jack (
×
2)
(for INPUT 3/4) L/R .... above 500 mVrms/10 k
Ω
AUDIO OUTPUT Output Stereo mini jack
L/R .... below the upper limit of
500 mVrms (national)/5 k
Ω
SPEAKER Output L/R .... 8 to 16
Ω
/2 W + 2 W (when 8
Ω
)
Control-related
RS-232C terminal: D-sub, 9-pin (male)
Combination In/Out Terminal: Mini-DIN, 6-pin
Control In/Out Terminal: Monaural mini-jack ( × 2)
Power requirements ................. AC 100 V to 120 V, 50/60 Hz
In-rush ............................................................... less than 30 A
Power factor .................................................... more than 0.95
Consumption ......................... 470 W
(NOTE 3) (0.6 W in standby)
External dimensions (without attachment stand)
.......................................... 1218 (W)
×
714 (H)
×
98 (D) mm
47-31/32 (W)
×
28-1/8 (H)
×
3-7/8 (D) in.
Weight (without attachment stand) ......................... 40.3 kg
(88 lbs. 14 oz)
Dimensions of packaging .. 1341 (W)
×
890 (H)
×
424 (D) mm
52-13/36 (W) × 35-1/16 (H) × 16-23/32 (D) in.
Weight when packaged .................................................. 53kg
(116 lbs. 14 oz)
Operating Temperature ................................. 0 to 40 °C (NOTE 4)
(32 to 104 °F)
Operating Humidity .............................................. 20 to 80 %
Operating atmospheric pressure ..................... 0.8 to 1.1 atm
Storage limitations (when installed)
Temperature .................................................. –20 to +60 °C
(–4 to 140 °F)
Humidity ............................................................. 20 to 90 %
Atmospheric pressure .................................... 0.6 to 1.5 atm
Storage limitations (when in original package)
Temperature .................................................. –40 to +60 °C
(–40 to 140 °F)
Humidity ............................................................. 20 to 90 %
Atmospheric pressure .................................... 0.6 to 1.5 atm
Stacking ............................................ Fewer than three tiers
Standard accessories
Power cord .............................................................................. 1
Remote control unit ................................................................ 1
AA battery ............................................................................... 2
Pin/BNC conversion adapter ................................................... 1
Wiping cloth ............................................................................ 1
Speed clamp ........................................................................... 2
Bead Band ............................................................................... 2
Operating instructions ............................................................. 1
Warranty card .......................................................................... 1
Remote control unit case ........................................................ 1
Display stand ........................................................................... 2
Large washer .......................................................................... 2
Small washer .......................................................................... 2
Hexagon socket head screw ...................................................
2
Specifications and external designs are subject to change without
notice.
