- 4 -
1000Base-T
LNK/ACT
1000/100
FDX
2.2 Rear Panel
The rear panel of the Switch indicates an AC inlet power socket, which accepts input power from 100 to
240VAC, 50-60Hz.
100-240V AC
50/60 H z 9600, N, 8, 1
Console
Figure 2: WGSD-1020 Switch rear panel
Power Notice:
1. The device is a power-required device, it means, it will not work till it is powered. If your networks
should active all the time, please consider using UPS (Uninterrupted Power Supply) for your device. It
will prevent you from network data loss or network downtime.
2. In some area, installing a surge suppression device may also help to protect your switch from being
damaged by unregulated surge or current to the Switch or the power adapter.
LED Color Function
LNK / ACT Green Lit: indicate the link through that port is successfully
established.
Blink: indicate that the switch is actively sending or
receiving data over that port.
LED Color Function
1000
100
Orange
Green
Lit: indicate that connection made through the
corresponding port is running at 1000Mbps.
Lit: indicate that connection made through the
corresponding port is running at 100Mbps.
LED Color Function
FDX Green Lit: indicate that the connection made through the
corresponding port is running in Full Duplex mode.
Blink: indicate that the connection is experiencing
collisions
