Base frame & shielding 1-1 – Locke MP User Manual
Page 3
13
14
14
13
1
24
11
15
3
8
14
13
12
10
7
9
21
16
21
19
18
15
22
5
22
17
22
5
22
22
20
22
22
5
6
4
MP3132
FP3132
2
23
REF. PART
QTY DESCRIPTION
NO. NO.
1 50026138
1 Deck
w/Decals
2 500033
1 Decal,
Locke
(Large)
3 50012616
2 Decal,
Danger
4 99498
1 R.H.
Shield
w/Decals
5 50012615
3 Decal,
Warning
6 98082
2 Decal.
Belt
Installation
7 89477
1 Decal,
Warranty
8 15165
3 HHCS
5/8”
x
1-3/4”
9 50021133
1 Gearbox
Stand
w/Decal
10 83105
1 Decal,
Warning
11 82619
1 Decal,
Danger
12 20414
4 Locknut,
Flange
5/8”
13 15916
4 Flatwasher
1/2”
REF. PART
QTY DESCRIPTION
NO. NO.
14 1056
4
HHCS 1/2” x 1-1/4” Gr.5
15 19518
4 Locknut,
Flange
1/2”
16 98253
1 Shield
Mount
Bracket
17 98174
1 Shield
w/Decal
18 44215
4
HHCS M8 x 1.25 x 15mm
19 44311
4 Lockwasher
M8
20 99499
1 L.H.
Shield
w/Decals
21 50014067
2 Cap
22 98284
7 Swell
Latch
23 50100010
1
Decal, Model (MP Series)
50100006
1 Decal,
Model
(FP
Series)
24 500034
2 Decal,
Locke
(Small)
Base Frame & Shielding
1-1
