Introduction
1-4
Front View
The following illustration shows the front view of your printer and
indicates the various main elements.
Top Cover
Cartridge
Compartment
Cover
(Not Available)
Control Panel
(Not Available)
Handle
Paper Out Tray
Paper Input
Tray
Ink Cartridge and
Carrier (inside)
Scanner Bed
Display
Scanner bed
Printer Components
Chapter 1
