IBM Parallel Attachment (Models 4I3 and 5I3)
|
The 4230 supports the IBM Parallel Printer Interface. A single 36-pin
|
connector is mounted on the adapter card.
|
The PC-parallel interface attaches to the host with a standard PC
|
Parallel Printer cable (IBM part 1525612) up to 1.8 m (6 ft) in length.
|
IBM Parallel Connector Pin Assignments
|
Pin
|
Number
|
Signal Name
|
Description
|
1
|
-STROBE
|
Strobe
|
2 - 9
|
DATA
|
Eight Data Lines
|
10
|
-ACKNLG
|
Acknowledge
|
11
|
BUSY
|
Busy
|
12
|
PE
|
Out of Paper
|
13
|
SLCT
|
Printer Selected
|
14
|
Unused
|
|
15
|
Unused
|
|
16
|
LOGIC GND
|
Logic Ground
|
17
|
CHASSIS GROUND
|
Chassis Ground
|
18
|
Unused
|
|
19 - 30
|
GROUND
|
Ground
|
31
|
-INIT
|
Initialize Printer
|
32
|
-ERROR
|
Printer Error
|
33
|
GROUND
|
Ground
|
34, 35
|
Unused
|
|
36
|
Unused
|
