Installation, Electrical specifications, Physical dimensions – Lincoln Electric MULTI-WELD SVM151-A User Manual
Page 8: Temperature ranges
A-2
A-2
INSTALLATION
MULTI-WELD 350
ELECTRICAL SPECIFICATIONS
Amps (DC+)
Volts (DC+)
Output Rating @ 50°C (122°F)
350
34
Input Rating @ 50°C (122°F)
165
80
Max. Input Range
50-113 (Peak)
Max. O.C.V.
78
Output Preset Range
30-350
15-40
PHYSICAL DIMENSIONS
Height
Width
Depth
Net Weight
11.6 in.
10.0 in.
21.5 in.
59.5 lbs.
295 mm
254 mm
546 mm
27.0 kg.
TEMPERATURE RANGES
Operating Temperature Range
Storage Temperature Range
-40 to +122°F
-40 to +185°F
-20 to +50°C
-40 to +85°C
TECHNICAL SPECIFICATIONS - MULTI-WELD 350 (K1735-1)
