Should a machine under test be rejected for any reason requiring the removal of any mechanical part that could
affect the machine’s electrical characteristics or if any electrical components are repaired or replaced, the machine
must be retested.

OUTPUT LOAD READINGS

OPEN CIRCUIT VOLTAGE

RETEST AFTER REPAIR

Maximum Idle Amps

Input Volts/Hertz

5
4

208/3/60
230/3/60
460/3/60
575/3/60

Volts

1-7 VDC

36 VDC Minimum

Amps

Output Control Setting

40-50

410

Minimum

Maximum

Mode

Open Circuit Volts

Maximum

Normal Range

Auxiliary Output (#31 - #32)

Auxiliary Output (#41 - #42 (#32A))

55 VDC

10-43 VDC

112/119 VAC

39/42 VAC

F-47

TROUBLESHOOTING & REPAIR

F-47

IDEALARC CV-300
